Sunny Portal: Đăng Ký Tài Khoản Sunny Webbox

You can present data from your PV plant in Sunny Portal using the Sunny WebBox. The Sunny Portal monitors the PV plant and displays the yield and power output. In addition, Sunny Portal can send useful reports via e-mail. Depending on your Sunny WebBox version, you can transmit data to Sunny Portal using a variety of connection types (e.g. analogor ISDN or DSL router). If the Sunny WebBox is unable to connect to the Sunny Portal, the Sunny WebBox will store the collected plant data in a ring buffer. The Sunny WebBox transmits the data to Sunny Portal with the next data upload. If the ring buffer is full, the Sunny WebBox will overwrite the oldest data. The time the ring buffer can bridge depends on the device type and number of the detected devices.

Note:
Possible delays in the visualisation
Evaluating the collected data takes time. Please note that it can take several minutes for Sunny Portal to display the data of your PV plant.

The procedure for registering the Sunny WebBox in the Sunny Portal is described below.

Procedure:

1. Log into the user interface of the Sunny WebBox

2. Select “WebBox > Settings > Data transmission” in the user interface.

3. Enter the name of your plant in the “Plant name” field. Sunny Portal displays the name of your plant.

4. Select the transmission method in the “Interface” field. The transmission method depends on the version of your Sunny WebBox.

5. Set the upload frequency.

6. Select “Yes” in the “Use Sunny Portal” field.

Information:
The plant identifier will be entered automatically.
In general, you do not have to change the preset number in the “Plant identifier” field. For Sunny Portal the number is a unique identifier of the plant.
If you have not yet registered at Sunny Portal, the Sunny WebBox will automatically enter the preset plant identifier in Sunny Portal after the first successful data upload. Sunny Portal sends the access data to the e-mail address you entered in the “Operator e-mail” field. You are now registered in Sunny Portal.
If you have already registered at Sunny Portal with the same plant (which may be the case, for instance, when exchanging the data logger), you have to adjust the plant identifier in the “Plant identifier” field.

7. Enter your e-mail address in the “Operator e-mail” field. Sunny Portal then sends your access data to the e-mail address entered.

8. Make a selection in the “Use Proxyserver” field and, if necessary, enter the IP address and the port of the proxy server in the “Proxyserver address” field.

9. Make a selection in the “Use authentication” field:

10. Enter the data for your proxy server in the “User name” and “Password” fields.

11. Select [Save].

12. Select “WebBox > Info”.

13. Select [Register] in the “Last Sunny Portal registration” field. The Sunny Portal password will be sent to the entered e-mail address.

The Sunny WebBox data transmission to Sunny Portal is configured.
On the “WebBox > Info” page, you can see when the Sunny WebBox last successfully transmitted data.

Additional information:

1) Setting Data Upload
The upload frequency setting is used to define how frequently the Sunny WebBox connects to the Sunny Portal or the external FTP server each day. You can also define the time when the Sunny WebBox connects to the Sunny Portal or the external FTP server. All data upload settings apply to both data uploads to the Sunny Portal as well as data uploads to an external FTP server.

1. Select “WebBox > Settings > Data transmission” in the user interface.
2. Select the upload frequency in the “Upload frequency per time window” field.
3. Select the maximum number of upload attempts per time window in the “Maximum number of upload attempts per time window” field.
4. Select [Save]

 The data upload is set.

Information:
Maximum number of upload attempts
If the data transmission from the Sunny WebBox to the Sunny Portal or external FTP server fails, the Sunny WebBox will make further attempts to transmit the data. The “Maximum number of upload attempts per time window” value specifies the number of data transmission attempts the Sunny WebBox makes within the defined time window.

2) Adjusting the Plant Identifier for Sunny Portal
Sunny Portal identifies your Sunny WebBox via the plant identifier. In the following cases, you must adjust the plant identifier in the Sunny WebBox:

• Data has already been sent to Sunny Portal via another communication device.
• The plant identifier set for the Sunny WebBox has been reset using the Reset button.
• The Sunny WebBox has been replaced with another Sunny WebBox.
• The WebBox is to be added to a plant that is already registered in Sunny Portal.

Perform the following steps to adjust the plant identifier of the Sunny WebBox for Sunny Portal:

1. Register at Sunny Portal (www.SunnyPortal.com).
2. Go to “Configuration > Plant properties” on the Sunny Portal page.
3. Copy the plant identifier to the clipboard.
4. Log into your Sunny WebBox as a user/installer.
5. Select “WebBox > Settings > Data transmission” in the user interface.
6. Delete the content of the “Plant identifier” field.
7. Paste the plant identifier from the clipboard into the “Plant identifier” field.
8. Select [Save].

The Sunny WebBox plant identifier for Sunny Portal has been adjusted.
